HYT-51F 2 inch vertical hose crimping machine

HYT-51F 2 inch vertical hose crimping machine

The side of HYT-51F vertical hose crimping machine is specially designed to add mold holders to facilitate the access and replacement of the molds, and the machine operation is more convenient and efficient.

The mold opening speed is fast, the weight is light, and the cost is reduced, and is not easy to be damaged, and reduces maintenance costs.

HYT-51F vertical hose crimping machine is equipped with a high box, which provides a wider space for the machine, making it easy to place machine parts and other necessary tools.

Hose capacity(max. inner diameter): 1/4" - 2" (4 wire)

Technical Parameter:

Model :HYT-51F

Crimping range: 1/4″ – 2″, 10sets

Crimp force(KN/Ton):5000/500

Max. Crimp range: 87mm

Opening:+30mm

Opening without dies：114m

Close Speed (mm/sec.):6s

Crimp Speed (mm/sec.): 2.3

Open Speed (mm/sec.): 8.2s

Voltage: 220V/380V

Power: 3KW/4KW

Drive: Electric

Machine (mm):860*640*1300mm

Weight:310kg

Main Features

1) Simple structure in linear type ,easy in installation and maintation.

2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

3) High pressure double crank to control the die opening and closing.

4) Running in a high automatization and intellectualization,no pollution

5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .

Machine in stocks . It can be arrange delivery at anytime . Wooden package!
